ASUS Pro WS WRX80E-SAGE SE WIFI AMD sWRX8 E-ATX Workstation Motherboard
৳ 0.00
Key Features
- Model: Pro WS WRX80E-SAGE SE WIFI
- Supported CPU: Threadripper PRO Series Processors for sWRX8 Socket
- Supported RAM: 8x DIMM, Max. 2048GB, DDR4 3200MHz
- 8 x SATA III, 3 x M.2, 2 x U.2
- Wi-Fi 6, Bluetooth v5.2
Description
Specification
| Basic Information | ||
| Supported CPU | AMD Socket sWRX8 for AMD Ryzen Threadripper PRO Series Processors | |
| Chipset | AMD WRX80 Chipset | |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | EATX(EEB) Form Factor 12.2 inch x 13 inch ( 30.98 cm x 33.02 cm ) |
|
| Audio | Realtek ALC4080 7.1 Surround Sound High Definition Audio CODEC – Impedance sense for front and rear headphone outputs – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking – High quality 120 dB SNR stereo playback output and 113 dB SNR recording input – Supports up to 32-Bit/384 kHz playback |
|
| Memory | ||
| Type | DDR4 | |
| Slots | 8 x DIMM | |
| Supported Memory | 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz ECC and Non-ECC, buffered and Un-buffered, U-DIMM, R-DIMM, 3DS R-DIMM and LR-DIMM Memory 8 Channel Memory Architecture |
|
| Maximum Memory | 2048GB | |
| Graphics | ||
| Graphics | Supports NVIDIA 4-Way/3-Way/2-Way SLI Technology | |
| Connector & Ports | ||
| USB (s) | Rear USB (Total 10 ports) 1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C) 9 x USB 3.2 Gen 2 port(s) (8 x Type-A + 1 x USB Type-C) Front USB (Total 7 ports) |
|
| LAN Port (s) | 1 x Intel X550-AT2 dual 10Gb Ethernet | |
| Wireless Communication module | Wi-Fi 6 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2 |
|
| Supported Storage | Total supports 3 x M.2 slots and 8 x SATA 6Gb/s ports AMD Ryzen Threadripper PRO Series Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes) M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes) U.2_1 slot supports U.2 NVMe device and up to 4 SATA devices* AMD WRX80 Chipset M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes) U.2_2 slot supports U.2 NVMe device and up to 4 SATA devices* 4 x SATA 6Gb/s ports ASMedia ASM1061 Controller 4 x SATA 6Gb/s ports |
|
| RAID | Supports NVMe RAID configurations via M.2 storages | |
| Audio | 5 x Audio jacks | |
| Internal I/O Ports | Fan and Cooling related 1 x 4-pin CPU Fan header(s) 1 x 4-pin CPU OPT Fan header(s) 6 x 4-pin Chassis Fan header(s) 1 x VRM heatsink Fan header 1 x Chipset Fan header Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connector 2 x 6-pin PCIe Graphics Card connector 1 x 8-pin PCIe Power connector Storage related 3 x M.2 slots (Key M) 8 x SATA 6Gb/s ports 2 x U.2 slots USB 1 x USB 3.2 Gen 2 connector (support(s) USB Type-C®) 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports BMC Related 1 x BMC switch 1 x IPMI switch 1 x Messange LED header 1 x Micro SD card socket 2 x LAN LED header(s) 1 x Location LED header 1 x Location button header 1 x PSU_SMB header 1 x SMART_PSU switch 1 x VGA switch 1 x VGA header 1 x VPP_I2C header Miscellaneous 1 x COM Port header 1 x FlexKey button 1 x Front Panel Audio header (AAFP) 1 x SPI TPM header (14-1pin) 1 x Start button 1 x 20-3 pin System Panel header with Chassis intrude function 1 x RTC Battery header 1 x Thermal Sensor header |
|
| Others | ||
| Special Features | ASUS Q-Design – Q-Code – Q-Connector – Q-DIMM – Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) – Q-Slot ASUS Thermal Solution – M.2 heatsink ASUS EZ DIY – BIOS FlashBack™ button – BIOS FlashBack™ LED – Clear CMOS button – ProCool II – Pre-mounted I/O shield – SafeSlot Bespoke Motherboard Design & Business Focused Features – Event Log in ASMB9-iKVM – 24/7 Reliability – Overcurrent Protection ASMB9-iKVM for KVM-over-Internet |
|
| Bundled Software | ASUS Exclusive Software Armoury Crate ASUS CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools DTS:X® Ultra Norton Anti-virus software (Free Trial version) WinRAR UEFI BIOS ASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years | |
Description
ASUS Pro WS WRX80E-SAGE SE WIFI AMD sWRX8 E-ATX Workstation Motherboard
The ASUS Pro WS WRX80E-SAGE SE WIFI Workstation Motherboard comes with AMD Socket sWRX8 for AMD Ryzen Threadripper PRO Series Processors. This E-ATX workstation motherboard is designed to provide a reliable foundation for professional creative workloads such as video editing and 3D rendering. The Pro WS WRX80E-Sage SE fully utilizes the large PCIe 4.0 data bandwidth to deliver high performance with compatible devices, such as the eight memory slots, which support up to 2048GB of DDR4-3200 octa-channel ECC buffered memory for automatic data error correction. It also has slots for up to eight SATA III drives and three M.2 PCIe 4.0 x4 SSDs that can be configured in RAID 0, 1, or 10. Two U.2 slots are also available, each of which can support up to four SATA devices via transfer cables purchased separately. Furthermore, its seven PCIe 4.0 x16 expansion slots can support high-performance devices such as NVIDIA SLI graphics cards in 2-way, 3-way, and 4-way configurations, allowing you to maximize your system’s graphical capabilities and accelerate rendering times. The dual 10G Ethernet ports provide high-speed data transfers with compatible networks and devices. Windows 10 64-bit is required to take advantage of all the motherboard’s features. The included ASUS Hyper M.2 x16 Gen 4 card allows you to add up to four additional M.2 PCIe 4.0 SSDs to your system and create a bootable RAID array. The card is designed to provide up to 256 Gb/s of bandwidth for smooth data transfers.
Buy ASUS Pro WS WRX80E-SAGE SE WIFI AMD sWRX8 E-ATX Workstation Motherboard from Star Tech
In Bangladesh, you can get original ASUS Pro WS WRX80E-SAGE SE WIFI AMD sWRX8 E-ATX Workstation Motherboard From Star Tech. We have a large collection of the latest ASUS motherboards to purchase. Order Online Or Visit your Nearest Qtech Shop to get yours at the lowest price. The ASUS Pro WS WRX80E-SAGE SE WIFI Workstation Motherboard comes with 3 3-year warranty.
What is the price of ASUS Pro WS WRX80E-SAGE SE WIFI Workstation Motherboard in Bangladesh?
The latest price of ASUS Pro WS WRX80E-SAGE SE WIFI Workstation Motherboard in Bangladesh is 0৳. You can buy the ASUS Pro WS WRX80E-SAGE SE WIFI Workstation Motherboard at the best price from our website or visit our showrooms.
